fastmatic® Traffic Barrier / Barrier Gate / Boom Gate / Palang Parkir / Portal Otomatis

HIGH SPEED BARRIER

for heavy traffic parking area

vg-900 Series is a specially design system for large commercial parking lots which need a quick treatment of parkers and safety for vehicle and passengers simultaneously.

The system has a 1.0 second of opening time for quick treatment of parkers and 2.0 second of closing time for the safety.

Opening time : 1.0 sec

Closing time : 2.0 sec

Smart breaking : Control based on data from the motor, almost no vibration at the end position

Voltage/ frequency free

No. limit switch

Battery backup operation on power failure

High Speed Intelligent Barrier G400 for commercial parking facility

Unique fast up and safe down movement

The main features G-400 are :

- Opening time 1.0 sec and,

- Closing Time 2.0 sec.

- Almost no vibration of the bar at the end positions.

- Minimized heat & noise, high efficiency epsilon motor.

- Frequency free, usable at any fequency of power without additional setting.

- Intelligent control of optimum acceleration and deceleration.

- No limit switch.

Housing :

- Cold Rolled sheet steel of 2mm thickness

- Zinc plating with powder coating finished

Mechanism :

- Direct connection of the motor and driving shaft

- Zinc plate finish of the lever and body

Technical Specification :

- Bar ( Aluminum Round Profile 3.0M)

- Opening Time 1.0 sec

- Closing Time 2.0 sec

- Frequency & Voltage ( free)

- Power Consumption ( max 200 watt)

- Dimension ( wxdxh) 350x350x1035 ( mm)

- Weight ( not incl boom) 58 Kgs

- Drive ( Inverter Motor = BLDC)
